TracoPower TRN 1-4811 DC/DC Converter 48V to 5V 200mA 1W SIL Case

TracoPower
Order Code:

07-8372

Brand: TracoPower MPN: TRN 1-4811
Qty Unit Price (Ex VAT)
1+ £8.76
5+ £8.49
10+ £8.22
25+ £7.87
50+ £7.53
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 25/01/2026

The TracoPower TRN 1-4811 is a DC/DC converter that converts 48 V DC to 5 V DC with a current output of 200 mA and a power rating of 1 W. It features a single output and is typically used in applications requiring voltage conversion and regulation. This reliable component is ideal for use in electronic devices and systems that need precise voltage levels.
Connection Solder pins
Dim (L x W x H) 7.7 x 11.9 x 15.1 mm
Efficiency (max.) 78%
Enclosure SIL
Height 15.1mm
Input voltage (max.) 75V DC
Insulation Voltage 1600V DC
Length 7.7mm
Max. output current 200mA
Min. input voltage 36V DC
Nominal Voltage 48V DC
Number of Outputs 1
Operating temperature (max.) 90°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 200mA
Output current (min.) 0mA
Output voltage (max.) 5V DC
Output voltage (min.) 5V DC
Output voltages +5V DC
Power 1W
Type DC/DC converter (print)
Width 11.9mm
