TracoPower TPP 30-109-J SMPSU 9V DC 3.34A 30W Reliable Power Supply

TracoPower
Order Code:

07-8343

Brand: TracoPower MPN: TPP 30-109-J
Qty Unit Price (Ex VAT)
1+ £47.86
5+ £46.42
10+ £44.98
25+ £43.08
50+ £41.52
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 25/01/2026

TracoPower's TPP 30-109-J is a compact and efficient 30 W switch mode power supply unit designed for PCB mounting. It delivers a stable 9 V DC output at 3.34 A, making it ideal for embedding in circuit boards. Often used in industrial and electronic applications, this PSU features solder lugs for secure connections.
Connection Connector
Dim (L x W x H) 100.3 x 38.1 x 25.4 mm
Height 25.4mm
Input voltage (max.) 264V AC
Length 100.3mm
Max. operating temperature (derating) 60°C
Max. output current 3.34A
Max. temperature 85°C
Min. input voltage 85V AC
Min. temperature -40°C
Misc Attribute 2 closed
Number of Outputs 1
Operating temperature (max.) 85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 3.34A
Output current (min.) 0mA
Output voltage (max.) 9V DC
Output voltage (min.) 9V DC
Power 30W
Type SMPSU
Width 38.1mm
