TracoPower TPP 30-105-J SMPSU 5V 6A 30W Single Output Power Supply

TracoPower
Order Code:

07-8341

Brand: TracoPower MPN: TPP 30-105-J
Qty Unit Price (Ex VAT)
1+ £56.19
5+ £54.51
10+ £52.82
25+ £50.57
50+ £48.33
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 28/12/2025

TracoPower's TPP 30-105-J is a printed circuit board power supply unit that delivers 5 V DC at 6 A, yielding a total of 30 W. It is designed for PCB mount with solder lugs, making it suitable for surface-mount applications. Typically used in various electronic devices, this SMPSU is ideal for compact and efficient power solutions.
Connection Connector
Dim (L x W x H) 100.3 x 38.1 x 25.4 mm
Height 25.4mm
Input voltage (max.) 264V AC
Length 100.3mm
Max. operating temperature (derating) 60°C
Max. output current 6A
Max. temperature 85°C
Min. input voltage 85V AC
Min. temperature -40°C
Misc Attribute 2 closed
Number of Outputs 1
Operating temperature (max.) 85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 6A
Output current (min.) 0mA
Output voltage (max.) 5V DC
Output voltage (min.) 5V DC
Power 30W
Type SMPSU
Width 38.1mm
