TracoPower TMR 6-2415WI DC/DC Converter 24V 250mA 6W 4:1 Range SIP8-Case

TracoPower
Standard range
Order Code:

07-8302

Brand: TracoPower MPN: TMR 6-2415WI
Qty Unit Price (Ex VAT)
1+ £21.08
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
11 in stock, despatched in 4 working days

TracoPower's TMR 6-2415WI is a high-efficiency DC/DC converter designed to deliver 24 V DC input to 24 V DC output with a current of 250 mA and a power rating of 6 W. It is an ideal choice for powering electronic circuits where isolation between input and output is critical. Typical applications include telecommunications equipment, industrial electronics, and distributed power architectures.
Type DC/DC converter (print)
Connection Solder pins
Dim (L x W x H) 21.8 x 15.3 x 9.1 mm
Efficiency (max.) 88%
Enclosure SIP 8
Height 9.1mm
Input voltage (max.) 36V DC
Insulation voltage 1600V DC
Length 21.8mm
Max. output current 250mA
Min. input voltage 9V DC
Misc Attribute TMR 6-2415WI
No. of outputs 1
Nominal voltage 24V DC
Operating temperature (max.) 71°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 250mA
Output voltage (max.) 24V DC
Output voltage (min.) 24V DC
Output voltages 24V DC
Power 6W
Weight 4.8g
Width 15.3mm
