TracoPower TMR 1-0522 DC/DC Converter 5V to 12V/-12V 2x Outputs 1W SIL-6

TracoPower
Standard range
Order Code:

07-8288

Brand: TracoPower MPN: TMR 1-0522
Qty Unit Price (Ex VAT)
1+ £10.37
5+ £10.07
10+ £9.75
25+ £9.33
50+ £8.92
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
7 in stock, despatched in 4 working days

The TracoPower TMR 1-0522 DC/DC converter provides efficient power conversion with 5 V DC input, offering dual outputs of 12 V and -12 V DC at 42 mA, and a power capacity of 1 W. This compact print converter by TracoPower is ideal for use in industrial and telecommunications applications requiring reliable voltage regulation. It features two isolated outputs, making it suitable for distributed power architectures and mixed analogue/digital circuits.
Type DC/DC converter (print)
Connection Solder pins
Dim (L x W x H) 17 x 7.62 x 14.2 mm
Efficiency (max.) 77%
Enclosure SIL 6
Height 14.2mm
Input voltage (max.) 9V DC
Insulation voltage 1500V DC
Length 17mm
Max. output current 42mA
Min. input voltage 4.5V DC
Misc Attribute TMR 1-0522
No. of outputs 2
Nominal voltage 5V DC
Operating temperature (max.) 85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 42mA
Power 1W
Weight 3.1g
Width 7.62mm
