TracoPower TMDC 20-4818 Converter 48V 420mA 20W 1 Output 2500V/DC Insulation

TracoPower
Order Code:

07-8250

Brand: TracoPower MPN: TMDC 20-4818
Qty Unit Price (Ex VAT)
1+ £51.21
5+ £49.67
10+ £48.13
25+ £46.09
50+ £44.04
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 28/12/2025

The TracoPower TMDC 20-4818 is a DC/DC converter module providing a 48 V DC input and output with a current rating of 420 mA and a power capacity of 20 W. Ideal for stable and efficient power conversion, it features a single output channel. This converter is typically used in industrial and automation applications requiring robust electrical performance.
Connection Screw terminal
Dim (L x W x H) 54 x 96 x 23.3 mm
Efficiency (max.) 89%
Height 23.3mm
Input voltage (max.) 75V DC
Insulation Voltage 2500V DC
Length 54mm
Max. output current 420mA
Min. input voltage 18V DC
Misc Attribute 1 20-4818 TMDC
Nominal Voltage 48V DC
Number of Outputs 1
Operating temperature (max.) 90°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 420mA
Output voltage (max.) 48V DC
Output voltage (min.) 48V DC
Output voltages 48V DC
Power 20W
Type DC/DC converter (module)
Width 96mm
