TracoPower TMDC 20-4815 DC/DC Converter 48V DC to 24V DC 20W 1 Output

TracoPower
Order Code:

07-8249

Brand: TracoPower MPN: TMDC 20-4815
Qty Unit Price (Ex VAT)
1+ £52.97
5+ £51.38
10+ £49.79
25+ £47.67
50+ £45.55
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 28/12/2025

The TracoPower TMDC 20-4815 is a DC/DC converter module featuring 48 V DC input, 24 V DC output, and 835 mA current rating, delivering up to 20 W with a single output. This compact converter is ideal for industrial and telecommunications applications where reliable power conversion is required. Its robust design ensures efficient performance even in demanding environments.
Connection Screw terminal
Dim (L x W x H) 54 x 96 x 23.3 mm
Efficiency (max.) 91%
Height 23.3mm
Input voltage (max.) 75V DC
Insulation Voltage 2500V DC
Length 54mm
Max. output current 835mA
Min. input voltage 18V DC
Misc Attribute 2 20-4815 TMDC
Nominal Voltage 48V DC
Number of Outputs 1
Operating temperature (max.) 90°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 835mA
Output voltage (max.) 24V DC
Output voltage (min.) 24V DC
Output voltages 24V DC
Power 20W
Type DC/DC converter (module)
Width 96mm
