The TracoPower TIW 24-112 is a 12V DC Enclosed Small Size DC Power Supply from the TIW series that has been designed particularly for applications in home and office installations. The compact module case fits in the standardised in-wall flush boxes or also can be mounted on walls. The power supply has a universal input range 93 to 264V AC, and complies fully with the safety and EMC standards requested for commercial and residential Class ll installations.
Typical applications are powering of electric devices used in home automation and in security systems like i.e. DC-motors, controllers, indicators, etc.
- High efficiency switching power supplies
- Easy installation into standard flush boxes
- Fully encapsulated plastic housing
- Dust and waterproof to IP 67
- Protection Class ll
- Safety approval to IEC/EN 60950-1
- EN 50178, EN 60335-1, UL 1310 class 2
- Ready to meet ErP directive
- Universal input range 93 to 264V AC
- Regulated output voltage
- Operating temperature range -25°C to +50°C
- Short circuit and overload protection
- 3-year product warranty
- Supplied with an Output Voltage of 12V DC
- Manufacturer's part: TracoPower TIW 24-112
| Power Rating |
12W |
| Dimensions |
24 x 48 x 51mm |
| Input Connection |
Strand |
| Number of Outputs |
1 |
| Output Connectors |
Strand |
| Output Current Max. |
1.0A |
| Output Current Min. |
1.0A |
| Output Voltage Max. |
12V |
| Output Voltage Min. |
12V |
| Supply Voltage Range |
93 to 264V |
| Temperature Range |
-25 to +50°C |
