TracoPower THN 10-4811WIR DC/DC converter 10W 2A 1 output

TracoPower THN 10-4811WIR is a high-performance DC-DC converter designed for precision and reliability in various engineering applications. With a power rating of 10 watts and a maximum current output of 2 amperes, this converter is suitable for tasks requiring stable and efficient DC voltage conversion. It features a single output, making it ideal for applications where compact and efficient power supply solutions are needed. The THN 10-4811WIR is commonly used in industrial automation, transportation, and telecommunications due to its robust design and ability to operate under demanding conditions. Its compact size allows for easy implementation into printed circuit boards, providing seamless integration into your project's power management system.

Output Voltage	5V DC
Connection	Solder pins
Content	1
Dimensions	(L x W x H) 25.4 x 25.4 x 9.9 mm
Efficiency (max.)	89%
Height	9.9mm
Input voltage (max.)	75V DC
Insulation Voltage	3000V DC
Length	25.4mm
Max. output current	2A
Min. input voltage	18V DC
No. of outputs	1
Operating temperature (max.)	80°C
Operating temperature (min.)	-40°C
Output current (max.) - rounded	2A
Output voltage (max.)	5.0V DC
Output voltage (min.)	5.0V DC
Power	10W
Product Type	DC/DC converter (print)
PSU features	DC-to-DC converter
Type	THN 10-4811WIR
Weight	16.5g
Width	25.4mm
