TracoPower THM 15-2422 DC/DC converter 15W 625mA 2 outputs 1 piece

TracoPower THM 15-2422 is a robust and reliable DC-DC converter designed for efficient power conversion needs. This component delivers a power output of 15 watts and a current capacity of 625 mA across two outputs, making it an ideal solution for a variety of electronic applications that require precise DC voltage regulation and isolation. Engineered for systems demanding compact power solutions, this print converter is suited for use in medical devices, industrial electronics, and telecommunications due to its high efficiency and compliance with stringent safety standards. The THM 15-2422 is an excellent choice for engineers seeking a dependable current rectifier for both low and high power systems, ensuring stable performance in mission-critical environments.

Connection	Solder pins
Content	1
Dimensions	(L x W x H) 40.60 x 25.40 x 10.20 mm
Efficiency (max.)	90%
Height	10.20mm
Insulation Voltage	5000V AC
Length	40.60mm
Max. output current	625mA
Maximum Input Volage	36V DC
Maximum Operating Temperature	85°C
Minimum Input Volage	18V DC
No. of outputs	2
Operating temperature (min.)	-40°C
Output current (max.) - rounded	625mA
Power	15W
Product Type	DC/DC converter (print)
Type	THM 15
Weight	24g
Width	25.40mm
