TracoPower THL 3-4811WISM SMD DC/DC Converter 48V to 5.1V 600mA 3W

TracoPower
Order Code:

07-8209

Brand: TracoPower MPN: THL 3-4811WISM
Qty Unit Price (Ex VAT)
1+ £19.40
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 28/12/2025

The TracoPower THL 3-4811WISM is a surface-mount DC/DC converter providing 48 V DC input and 5.1 V DC output at 600 mA, delivering up to 3 W of power. With its compact single-output design, it's ideal for space-constrained electronic applications requiring reliable voltage conversion. Typical uses include telecommunications, industrial control systems, and test equipment.
Connection SMD
Dim (L x W x H) 18.1 x 24 x 8 mm
Efficiency (max.) 78%
Enclosure SMD
Height 8mm
Input voltage (max.) 75V DC
Insulation Voltage 1500V DC
Length 18.1mm
Max. output current 600mA
Min. input voltage 18V DC
Nominal Voltage 48V DC
Number of Outputs 1
Operating temperature (max.) 85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 600mA
Output voltage (max.) 5.1V DC
Output voltage (min.) 5.1V DC
Output voltages 5.1V DC
Power 3W
Type DC/DC converter (SMD)
Width 24mm
