TracoPower TES 2-0513M DC/DC Converter 5V to 15V 133mA 2W SMD 1 Output

TracoPower
Standard range
Order Code:

07-8187

Brand: TracoPower MPN: TES 2-0513M
Qty Unit Price (Ex VAT)
1+ £24.42
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
5 in stock, despatched in 4 working days

The TracoPower TES 2-0513M is a surface-mounted DC/DC converter with a 5 V DC input and 15 V DC output, handling up to 133 mA with a power rating of 2 W. Manufactured by TracoPower, it features a single output and is ideal for applications requiring efficient voltage conversion in compact spaces. This converter is commonly used in telecommunications and industrial electronics.
Type DC/DC converter (SMD)
Connection SMD
Dim (L x W x H) 24 x 18.1 x 9 mm
Efficiency (max.) 66%
Enclosure SMD
Height 9mm
Input voltage (max.) 5.5V DC
Insulation voltage 4000V DC
Length 24mm
Max. output current 133mA
Min. input voltage 4.5V DC
Misc Attribute TES 2-0513M
No. of outputs 1
Nominal voltage 5V DC
Operating temperature (max.) 80°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 133mA
Output voltage (max.) 15V DC
Output voltage (min.) 15V DC
Output voltages 15V DC
Power 2W
Weight 3.2g
Width 18.1mm
