TracoPower TEP 160-4815 DC/DC Converter 48V to 24V 6.5A 160W 1 Output

TracoPower
Order Code:

07-8173

Brand: TracoPower MPN: TEP 160-4815
Qty Unit Price (Ex VAT)
1+ £163.05
5+ £158.15
10+ £153.26
25+ £146.75
50+ £143.98
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 25/01/2026

The TracoPower TEP 160-4815 DC/DC converter offers a conversion from 48 V DC to 24 V DC with a maximum output of 6.5 A and 160 W, featuring one output channel. This reliable direct current converter is suitable for various industrial and telecommunications applications requiring stable power supply. As a robust and efficient component, it is ideal for use in environments demanding high performance and longevity.
Connection Solder pins
Dim (L x W x H) 57.9 x 17.8 x 61 mm
Efficiency (max.) 92%
Height 61mm
Input voltage (max.) 75V DC
Insulation Voltage 1600V DC
Length 57.9mm
Max. output current 6.5A
Min. input voltage 33V DC
Nominal Voltage 48V DC
Number of Outputs 1
Operating temperature (max.) 75°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 6.5A
Output voltage (max.) 24V DC
Output voltage (min.) 24V DC
Output voltages 24V DC
Power 160W
Type DC/DC converter (print)
Width 17.8mm
