TracoPower TEP 160-4813WIR DC/DC Converter 48V DC to 15V DC 160W 1 Output

TracoPower
Standard range
Order Code:

07-8172

Brand: TracoPower MPN: TEP 160-4813WIR
Qty Unit Price (Ex VAT)
1+ £185.70
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
Available to back order

TracoPower manufactures the TEP 160-4813WIR, a DC/DC converter providing 48 V DC input to 15 V DC output at 10 A and 160 W with a single output. This robust converter is ideal for industrial applications requiring efficient power conversion. The TEP 160-4813WIR ensures reliable performance, making it suitable for use in railway and harsh environment systems.
Type DC/DC converter (print)
Connection Solder pins
Dim (L x W x H) 57.9 x 17.8 x 61 mm
Efficiency (max.) 91%
Height 61mm
Input voltage (max.) 75V DC
Insulation voltage 1600V DC
Length 57.9mm
Max. output current 10A
Min. input voltage 18V DC
Misc Attribute TEP 160-4813WIR
No. of outputs 1
Nominal voltage 48V DC
Operating temperature (max.) 75°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 10A
Output voltage (max.) 15V DC
Output voltage (min.) 15V DC
Output voltages 15V DC
Power 160W
Weight 105g
Width 17.8mm
