TracoPower TBA 2-2413 DC/DC converter 130mA 2W 1 output s

TracoPower TBA 2-2413 is a high-efficiency DC-DC converter designed for reliable power management in electronic systems. This compact unit provides a single output with a current rating of 130 mA and a power output of 2 watts, making it suitable for applications requiring efficient voltage conversion with minimal energy loss. Encapsulated in a SIP (Single Inline Package) format, this converter is ideal for integration into printed circuit boards where space is at a premium. It caters to a range of engineering applications, including telecommunications, industrial automation, and portable electronic devices, where consistent voltage regulation is critical for optimal performance. The TBA 2-2413's robust design ensures stable operation across a variety of environments, providing engineers with a reliable solution for their DC power conversion needs.

Connection	Solder pins
Content	1
Dimensions	(L x W x H) 19.60 x 7.60 x 10.20 mm
Efficiency (max.)	84%
Height	10.20mm
Insulation Voltage	1500V DC
Length	19.60mm
Max. output current	130mA
Maximum Input Volage	26.4V DC
Maximum Operating Temperature	90°C
Minimum Input Volage	21.6V DC
No. of outputs	1
Operating temperature (min.)	-40°C
Output current (max.) - rounded	130mA
Output voltage (max.)	15.0V DC
Output voltage (min.)	15.0V DC
Power	2W
Product Type	DC/DC converter (print)
Type	TBA 2
Weight	2.80g
Width	7.60mm
