TracoPower TBA 2-1212 DC/DC converter 165mA 2W 1 output

TracoPower TBA 2-1212 is a DC-DC converter designed to deliver efficient power conversion in compact electronic systems. This converter provides a single output with a capacity of 2 watts and is capable of handling up to 165 milliamperes. Its compact design makes it ideal for use in printed circuit board applications where space is at a premium, and it suits a variety of industrial and telecommunications equipment. With its robust construction, this converter is particularly useful in environments that require reliable current rectification and voltage conversion from one DC level to another. The TBA 2-1212 is essential for engineers looking to optimise their designs with a high-performance DC/DC converter while maintaining efficiency and reliability.

Connection	Solder pins
Content	1
Dimensions	(L x W x H) 19.60 x 7.60 x 10.20 mm
Efficiency (max.)	82%
Height	10.20mm
Insulation Voltage	1500V DC
Length	19.60mm
Max. output current	165mA
Maximum Input Volage	13.20V DC
Maximum Operating Temperature	90°C
Minimum Input Volage	10.8V DC
No. of outputs	1
Operating temperature (min.)	-40°C
Output current (max.) - rounded	165mA
Output voltage (max.)	12.0V DC
Output voltage (min.)	12.0V DC
Power	2W
Product Type	DC/DC converter (print)
Type	TBA 2
Weight	2.80g
Width	7.60mm
