TracoPower TBA 2-0513 DC/DC converter 130 mA 2 W 1 output

TracoPower TBA 2-0513 is a compact, isolated DC-DC converter designed to efficiently convert a DC input voltage to a regulated DC output. With an output current of 130 mA and a power rating of 2 W, this single-output converter offers high reliability and performance within its specified parameters. It is particularly suited for applications requiring isolation and voltage step-up or step-down, such as in industrial control systems, communication equipment, or instrumentation applications. The TBA 2-0513 achieves efficient power conversion with minimal power loss, thanks to its advanced design, making it ideal for use on printed circuit boards where space and efficiency are critical. Its robust construction and compliance with relevant industry standards ensure dependable operation in various environmental conditions.

Power Rating	2W
Connection	Solder pins
Content	1
Dimensions	(L x W x H) 19.60 x 7.60 x 10.20 mm
Efficiency (max.)	82%
Height	10.20mm
Insulation Voltage	1500V DC
Length	19.60mm
Max. output current	130mA
Maximum Input Volage	5.50V DC
Maximum Operating Temperature	90°C
Minimum Input Volage	4.5V DC
No. of outputs	1
Operating temperature (min.)	-40°C
Output current (max.) - rounded	130mA
Output voltage (max.)	15.0V DC
Output voltage (min.)	15.0V DC
Power	2W
Product Type	DC/DC converter (print)
Type	TBA 2
Weight	2.80g
Width	7.60mm
