TracoPower TBA 1-0521E DC/DC converter 1W 100mA 2 outputs

TracoPower TBA 1-0521E is a high-efficiency DC-DC converter specifically designed for applications requiring reliable voltage conversion in compact spaces. This converter offers a power rating of 1 W, supporting dual outputs with a current capacity of up to 100 mA. Engineered for precise energy management, the TBA 1-0521E ensures stable performance across varied load conditions, making it ideal for use in printed circuit boards where efficient power distribution is critical. Common applications include telecommunications, industrial electronics, and instrumentation systems, where consistent power regulation is paramount. This component is widely appreciated for its robust functionality in compact form factors, aligning with contemporary engineering requirements for space-efficient power solutions.

Connection	Solder pins
Content	1
Dimensions	(L x W x H) 19.50 x 6 x 9.50 mm
Efficiency (max.)	79%
Height	9.50mm
Insulation Voltage	1500V DC
Length	19.50mm
Max. output current	100mA
Maximum Input Volage	5.50V DC
Maximum Operating Temperature	95°C
Minimum Input Volage	4.5V DC
No. of outputs	2
Operating temperature (min.)	-40°C
Output current (max.) - rounded	100mA
Power	1W
Product Type	DC/DC converter (print)
Type	TBA 1E
Weight	2.30g
Width	6mm
