Phoenix Contact 2966265 PLC Interface Terminal with Screw Connection

The Phoenix Contact 2966265 PLC-RSC-24DC/21AU is an interface relay with a screw connector configuration. It is typically used in electromechanical applications to ensure reliable signal switching between automation systems. This single relay contact is suitable for contexts requiring robust interfacing solutions within control systems.

Type	Interface relay
Input Voltage	24V DC
Contact Configuration	1CO
Switching Current	50mA
Width	6.2mm
Height	80mm
Complete with socket	true
Connection	Screw terminal
Contact Material	AgSnO + gold plating
Degree of protection (IP)	IP20
Depth	94mm
Dim	(W x H x D) 6.2 x 80 x 94 mm
Drive, polarization	Polarized
Drive, switching attitude	Mono stable
IP Rating	IP20
Material contact	N/A
Material of contact insert	Other
Material of contact surface	Gold
Max. starting current	N/AA
Max. temperature	+60°C
Min. temperature	-40°C
Misc Attribute 1	PLC-RSC- 24DC/21AU
Misc Attribute 2	Screw connector
Nominal Current	0.009A
Number of contacts as change-over contact	1
Number of contacts as normally closed contact	0
Number of contacts as normally open contact	0
Operating voltage AC 50 Hz	- - -V
Operating voltage AC 60 Hz	- - -V
Operating voltage DC	- - -V
Rated control supply voltage AC 50 Hz	- - -V
Rated control supply voltage AC 60 Hz	- - -V
Rated control supply voltage DC	18.5 - 33.6V
Relay technology category according to IEC 61810-7	N/A
Switching Capacity	36 V/DC/30V AC
Type of electric connection	Screw connection
Type of switch contact	Single contact
Voltage type (operating voltage)	N/A
Voltage type for actuating	DC
With detachable clamps	false
With forced-guided contacts	false
With LED indication	true
