MW Mean Well XDR-75E-36 Open & DIN Power Supply Units

Mean Well XDR-75E-36 is an open and DIN rail power supply unit, designed for industrial applications requiring reliable and efficient power conversion. This DIN power supply module provides a robust solution for a range of critical environments, with the capability to be mounted on a standard rail for ease of installation. It delivers a nominal output of 75 watts at 36 volts, making it suitable for powering various industrial devices and systems. The XDR-75E-36 is engineered to fit seamlessly into industrial automation, process control systems, and machinery, offering stability and performance within its operational specifications. This rail mount power supply unit is also equipped with necessary protection features to ensure durability and longevity in demanding settings.

Type	Rail mounted PSU (DIN)
Number of Outputs	1
Power Rating	75W
Content	1
Depth	116mm
Dimensions (L x W x H)	116 x 30 x 125.2mm
Efficiency	91%
Height	125.2mm
IP Rating	Protection class I
Max. output current 1	2.1A
Max. temperature	-40°C
Maximum input voltage	264V
Maximum Operating Temperature	+70°C
Maximum Temperature	-40°C
Min. temperature	+70°C
Minimum Input Voltage	85V
Minimum Operating Temperature	+70°C
Nominal value output voltage 1	36V
Operating temperature (min.)	-40°C
Output current (max.) - rounded	2.1A
Output voltage (max.)	36V
Power	75.6W
Product Type	Rail mounted PSU (DIN)
Type of electric connection	Screw terminal
Width	30mm
