Mean Well XDR-480E-36 is a robust open and DIN rail power supply unit designed for reliable performance in various industrial applications. This particular model, identified by the alternate description 3431216, is engineered to deliver a stable output voltage and maintain efficiency across a wide range of operational temperatures. With a power output of 480 watts and a nominal output voltage of 36 volts, it is highly suitable for integration in industrial automation systems, control panels, and other environments where space-saving and efficient power management are essential. The open frame design facilitates easy installation on standard DIN rails, ensuring compatibility with existing infrastructure and enabling seamless implementation in complex electrical systems. This power supply unit offers durable and consistent power delivery, making it an ideal choice for engineers seeking dependable performance in harsh industrial conditions.
| Type |
Rail mounted PSU (DIN) |
| Number of Outputs |
1 |
| Power Rating |
480W |
| Content |
1 |
| Depth |
125mm |
| Dimensions (L x W x H) |
125 x 48 x 125.2mm |
| Efficiency |
95.5% |
| Height |
125.2mm |
| IP Rating |
Protection class I |
| Max. output current 1 |
13.3A |
| Max. temperature |
-40°C |
| Maximum input voltage |
264V |
| Maximum Operating Temperature |
+70°C |
| Maximum Temperature |
-40°C |
| Min. temperature |
+70°C |
| Minimum Input Voltage |
85V |
| Minimum Operating Temperature |
+70°C |
| Nominal value output voltage 1 |
36V |
| Operating temperature (min.) |
-40°C |
| Output current (max.) - rounded |
13.3A |
| Output voltage (max.) |
36V |
| Power |
478.8W |
| Product Type |
Rail mounted PSU (DIN) |
| Type of electric connection |
Screw terminal |
| Width |
48mm |
