MW Mean Well XDR-240E-12 Power Supply Unit Open & DIN installation 240W 12V

Mean Well XDR-240E-12 is a robust open and DIN rail mount power supply unit, designed for versatile and reliable operation in industrial environments. Delivering a power output of 240 watts at a stable 12 volts, it is engineered for seamless integration into various DIN rail systems, making it ideal for applications requiring robust and consistent power delivery. Typical uses include powering industrial automation systems, control panels, and communications equipment where efficiency and space-saving installation are paramount. This power supply module is built to meet the rigorous demands of modern industrial settings, ensuring durability and performance across a range of operating conditions.

Type	Rail mounted PSU (DIN)
Number of Outputs	1
Power Rating	240W
Content	1
Depth	116mm
Dimensions (L x W x H)	116 x 40 x 125.2mm
Efficiency	94%
Height	125.2mm
IP Rating	Protection class I
Max. output current 1	20A
Max. temperature	-40°C
Maximum input voltage	264V
Maximum Operating Temperature	+70°C
Maximum Temperature	-40°C
Min. temperature	+70°C
Minimum Input Voltage	85V
Minimum Operating Temperature	+70°C
Nominal value output voltage 1	12V
Operating temperature (min.)	-40°C
Output current (max.) - rounded	20A
Output voltage (max.)	12V
Power	240W
Product Type	Rail mounted PSU (DIN)
Type of electric connection	Screw terminal
Width	40mm
