Mean Well XDR-120E-48 is a robust DIN rail power supply unit designed for industrial applications, providing a reliable 48V output at 120W of power. This DIN power supply module is engineered to fit seamlessly onto DIN rails, ensuring convenient and space-efficient installation in electrical cabinets. Its high efficiency and durability make it ideal for industrial control panels, automation systems, and machinery where consistent power delivery is crucial. The XDR-120E-48 maintains regulated voltage output with low ripple and noise, enhancing its performance in sensitive electronic environments.
| Type |
Rail mounted PSU (DIN) |
| Number of Outputs |
1 |
| Power Rating |
120W |
| 1st secondary output voltage |
48V |
| 2nd secondary output voltage |
48V |
| 3rd secondary output voltage |
48V |
| Content |
1 |
| Depth |
116mm |
| Dimensions (L x W x H) |
116 x 30 x 125.2mm |
| Efficiency |
91% |
| Height |
125.2mm |
| IP Rating |
Protection class I |
| Max. output current 1 |
2.5A |
| Max. temperature |
-40°C |
| Maximum input voltage |
264V |
| Maximum Operating Temperature |
+70°C |
| Maximum Temperature |
-40°C |
| Min. temperature |
+70°C |
| Minimum Input Voltage |
85V |
| Minimum Operating Temperature |
+70°C |
| Nominal value output voltage 1 |
48V |
| Operating temperature (min.) |
-40°C |
| Output current (max.) - rounded |
2.5A |
| Output voltage (max.) |
48V |
| Output voltage stabilized |
48V |
| Power |
120W |
| Product Type |
Rail mounted PSU (DIN) |
| Rated supply voltage AC 50 Hz |
48V |
| Rated supply voltage AC 60 Hz |
48V |
| Rated supply voltage DC |
48V |
| Type of electric connection |
Screw terminal |
| Width |
30mm |
