Murrelektronik 9000-11112-0921111 Rail PSU 28V DC 5A DIN Mount 1 Output

The Murrelektronik rail mounted PSU (DIN) provides a 28 V DC output with a current rating of 5 A. It features a single output suitable for various industrial applications. This power supply unit is ideal for use in rail-mounted systems, ensuring a reliable power supply for industrial equipment.

Nominal value output current 1	5A
Number of Outputs	1
Depth	138mm
Dimensions (L x W x H)	138 x 50 x 123mm
Efficiency	94.50%
Height	123mm
Input Voltage	85 -250V
Inputs	1.3A
IP Rating	IP20
Max. operating temperature (derating)	+70°C
Max. output current 1	5A
Maximum Operating Temperature	+60°C
Maximum Temperature	+60°C
Min. operating temperature (derating)	-40°C
Min. temperature	-40°C
Nominal value output voltage 1 [DC]	28V
Operating temperature (min.)	-40°C
Output type (power supply units)	Adjustable
Phases	1
Type of electric connection	Spring-loaded terminal
Voltage type (supply voltage)	Rail mounted PSU (DIN)
Width	50mm
