Mean Well XLG-100-L-A XLG-series LED driver 100W 350-1050mA 71-142V DC

Mean Well
Standard range
Order Code:

05-1918

Brand: Mean Well MPN: XLG-100-L-A
Qty Unit Price (Ex VAT)
1+ £26.81
10+ £24.13
25+ £23.17
50+ £22.40
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
4 in stock, despatched in 4 working days

The Mean Well XLG-100-L-A LED driver provides constant power output at 100 W, with adjustable current ranging from 350 to 1050 mA and voltage between 71 to 142 V DC. It is suitable for outdoor use, equipped with surge protection and overvoltage features, and is approved for use on furniture and flammable surfaces. Typical applications include powering LED lighting systems, such as LED strips and fixtures, in both indoor and outdoor settings.
Type LED driver
Connection Open end cable
Dim (L x W x H) 140 x 63 x 32 mm
Factory colour Metal
Height 32mm
IP rating IP67
Length 140mm
Max. output current 1050mA
Max. power 100W
Max. temperature +90°C
Min. temperature -40°C
Misc Attribute 1 Constant power
Misc Attribute 2 Pulsed
No. of inputs 1
No. of outputs 1
Output current (max.) - rounded 1.05A
Output current (min.) 350mA
Output voltage (max.) 142V DC
Output voltage (min.) 71V DC
Power range 100 W (max)
Protection class I
Test mark CE, CB, MM, ENEC, UL
Weight 580g
Width 63mm
