Mean Well SPU01L-15 DC/DC converter 67 mA 1 W 1 output -40 to 90°C

Mean Well
Standard range
Order Code:

05-1857

Brand: Mean Well MPN: SPU01L-15
Qty Unit Price (Ex VAT)
1+ £2.47
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
8 in stock, despatched in 4 working days

The Mean Well SPU01L-15 is a DC/DC converter module with a 67 mA current rating and 1 W output. It features a single output configuration, making it suitable for applications requiring isolated power transformation. Typical uses include powering sensitive electronic devices or circuits that demand a stable DC supply.
Type DC/DC converter (module)
Connection Pins
Dim (L x W x H) 19.5 x 6.1 x 10.2 mm
Efficiency (max.) 79%
Height 10.2mm
Input voltage (max.) 5.5V DC
Insulation voltage 1500V DC
Length 19.5mm
Max. output current 67mA
Min. input voltage 4.5V DC
Misc Attribute SPU01L-15
No. of outputs 1
Operating temperature (max.) +90°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 67mA
Output voltage (max.) 15V DC
Power 1W
PSU features DC-to-DC converter
Weight 1.8g
Width 6.1mm
