Mean Well SPBW03G-15 DC/DC converter 3W 200mA 1 output 1500V isolation

Mean Well
Standard range
Order Code:

05-1845

Brand: Mean Well MPN: SPBW03G-15
Qty Unit Price (Ex VAT)
1+ £6.37
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
2 in stock, despatched in 4 working days

The Mean Well SPBW03G-15 is a direct current converter module with a single output delivering up to 200 mA and 3 watts. It is designed for efficient DC/DC conversion, ideal for powering low-power devices. Typical applications include industrial and telecommunications equipment where stable voltage conversion is required.
Type DC/DC converter (module)
Connection Pins
Dim (L x W x H) 21.8 x 9.2 x 11.1 mm
Efficiency (max.) 84%
Height 11.1mm
Input voltage (max.) 75V DC
Insulation voltage 1500V DC
Length 21.8mm
Max. output current 200mA
Min. input voltage 18V DC
Misc Attribute SPBW03G-15
No. of outputs 1
Operating temperature (max.) +85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 200mA
Output voltage (max.) 15V DC
Power 3W
PSU features DC-to-DC converter
RoHS-compliant Yes
Weight 4.8g
Width 9.2mm
