Mean Well SPAN02B-03 dc/dc converter 2W 500mA SIP 1500VDC insulation

Mean Well
Order Code:

05-1812

Brand: Mean Well MPN: SPAN02B-03 EAN-13: 4021087041119
Qty Unit Price (Ex VAT)
1+ £6.89
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
18 in stock, despatched in 4 working days

The Mean Well SPAN02B-03 is a direct current converter module providing a 500 mA output with a power rating of 2 W. It features a single output design, making it suitable for applications requiring efficient DC-to-DC conversion. Typical uses include power supply solutions in electronic circuitry that require voltage regulation and conversion.
Connection Pins
Dim (L x W x H) 21.8 x 9.2 x 11.1 mm
Efficiency (max.) 76%
Height 11.1mm
Input voltage (max.) 36V DC
Insulation Voltage 1500V DC
Length 21.8mm
Max. output current 500mA
Min. input voltage 18V DC
Number of Outputs 1
Operating temperature (max.) +90°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 500mA
Output voltage (max.) 3.3V DC
Power 2W
PSU features DC-to-DC converter
Type DC/DC converter (module)
Width 9.2mm
