Mean Well SPA01A-15 DC/DC converter 67mA 1W 1 output 1pc

Mean Well
Order Code:

05-1805

Brand: Mean Well MPN: SPA01A-15 EAN-13: 4021087033541
Qty Unit Price (Ex VAT)
1+ £8.11
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 20/12/2025

The Mean Well SPA01A-15 is a DC/DC converter module with a current rating of 67 mA and delivers up to 1 W of power. It features a single output, making it suitable for applications requiring efficient voltage conversion in compact spaces. Typical uses include powering low-power electronic devices where stable DC voltage is required.
Output Voltage 15V DC
Input Voltage Range 18V DC
Output Current 6mA
Number of Outputs 1
Connection Pins
Dim (L x W x H) 17.4 x 7.75 x 11.1 mm
Efficiency (max.) 79%
Height 11.1mm
Insulation Voltage 1500V DC
Length 17.4mm
Max. output current 67mA
Min. input voltage 9V DC
Operating temperature (max.) +90°C
Operating temperature (min.) -40°C
Power 1W
PSU features DC-to-DC converter
Type DC/DC converter (module)
Width 7.75mm
