Mean Well SMU02N-15 DC/DC converter module 133mA 2W 1 output 1pc

Mean Well
Standard range
Order Code:

05-1802

Brand: Mean Well MPN: SMU02N-15
Qty Unit Price (Ex VAT)
1+ £5.10
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
8 in stock, despatched in 4 working days

The Mean Well SMU02N-15 is a DC/DC converter module with a current rating of 133 mA and a power output of 2 W. It features a single output, providing efficient power conversion for various electronic applications. This compact module is ideal for use in powering small devices and embedded systems that require stable direct current.
Type DC/DC converter (module)
Connection Pins
Dim (L x W x H) 11.6 x 7.5 x 10.14 mm
Efficiency (max.) 84%
Height 10.14mm
Input voltage (max.) 26.4V DC
Insulation voltage 1500V DC
Length 11.6mm
Max. output current 133mA
Min. input voltage 21.6V DC
Misc Attribute SMU02N-15
No. of outputs 1
Operating temperature (max.) +85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 133mA
Output current (min.) 27mA
Output voltage (max.) 15V DC
Power 2W
PSU features DC-to-DC converter
Weight 1.3g
Width 7.5mm
