Mean Well SMU02N-05 DC/DC converter 2W 400mA 1 output

Mean Well
Standard range
Order Code:

05-1800

Brand: Mean Well MPN: SMU02N-05
Qty Unit Price (Ex VAT)
1+ £5.37
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
2 in stock, despatched in 4 working days

The Mean Well SMU02N-05 is a DC/DC converter module with a power rating of 2 W and a current output of 400 mA. It is suitable for converting direct current in various electronic applications requiring reliable power supply management. Typical uses include powering low-voltage devices and ensuring stable voltage output in compact electronic systems.
Type DC/DC converter (module)
Connection Pins
Dim (L x W x H) 11.6 x 7.5 x 10.14 mm
Efficiency (max.) 80%
Height 10.14mm
Input voltage (max.) 26.4V DC
Insulation voltage 1500V DC
Length 11.6mm
Max. output current 400mA
Min. input voltage 21.6V DC
Misc Attribute SMU02N-05
No. of outputs 1
Operating temperature (max.) +85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 400mA
Output current (min.) 80mA
Output voltage (max.) 5V DC
Power 2W
PSU features DC-to-DC converter
Weight 1.3g
Width 7.5mm
