Mean Well SMU02M-12 DC/DC converter module 2W 167mA 1 output 1pc

Mean Well
Standard range
Order Code:

05-1798

Brand: Mean Well MPN: SMU02M-12
Qty Unit Price (Ex VAT)
1+ £5.27
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
2 in stock, despatched in 4 working days

The Mean Well SMU02M-12 is a DC/DC converter module delivering 167 mA at 2 W with a single output. This compact converter is ideal for applications requiring efficient voltage regulation and power conversion in electronic devices. It is suitable for use in industrial control systems and communication equipment.
Type DC/DC converter (module)
Connection Pins
Dim (L x W x H) 11.6 x 7.5 x 10.14 mm
Efficiency (max.) 85%
Height 10.14mm
Input voltage (max.) 13.2V DC
Insulation voltage 1500V DC
Length 11.6mm
Max. output current 167mA
Min. input voltage 10.8V DC
Misc Attribute SMU02M-12
No. of outputs 1
Operating temperature (max.) +85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 167mA
Output current (min.) 33mA
Output voltage (max.) 12V DC
Power 2W
PSU features DC-to-DC converter
Weight 1.3g
Width 7.5mm
