Mean Well SKMW30F-15 DC/DC converter 2A 30W 1 output -40°C to 85°C range

Mean Well
Standard range
Order Code:

05-1775

Brand: Mean Well MPN: SKMW30F-15
Qty Unit Price (Ex VAT)
1+ £35.64
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
2 in stock, despatched in 4 working days

The Mean Well SKMW30F-15 is a DC/DC converter with a 30 W power rating and 2 A current capacity, providing a single output. It is ideal for applications requiring stable voltage conversion in compact electronic systems. This converter is suitable for use in telecommunications, data communications, and distributed power architectures.
Type DC/DC converter
Connection Pins
Dim (L x W x H) 25.4 x 25.4 x 10.2 mm
Efficiency (max.) 89%
Height 10.2mm
Input voltage (max.) 36V DC
Insulation voltage 1500V DC
Length 25.4mm
Max. output current 2A
Min. input voltage 9V DC
Misc Attribute SKMW30F-15
No. of outputs 1
Operating temperature (max.) +85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 2A
Output voltage (max.) 15V DC
Power 30W
PSU features DC-to-DC converter
RoHS-compliant Yes
Weight 18g
Width 25.4mm
