Mean Well SKMW20F-15 DC/DC converter 20W 1.33A 1 output wide temp range

Mean Well
Order Code:

05-1768

Brand: Mean Well MPN: SKMW20F-15 EAN-13: 4021087041423
Qty Unit Price (Ex VAT)
1+ £40.10
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well SKMW20F-15 DC/DC converter is a direct current converter with a 1.33 A current rating and a 20 W power capacity. It features one output and is typically used in applications requiring reliable voltage conversion and regulation. This converter is suitable for industrial and commercial settings where consistent DC power is essential.
Connection Pins
Dim (L x W x H) 25.4 x 25.4 x 10.2 mm
Efficiency (max.) 88%
Height 10.2mm
Input voltage (max.) 36V DC
Insulation Voltage 1500V DC
Length 25.4mm
Max. output current 1.33A
Min. input voltage 9V DC
Number of Outputs 1
Operating temperature (max.) +85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 1.33A
Output voltage (max.) 15V DC
Power 20W
PSU features DC-to-DC converter
Type DC/DC converter
Width 25.4mm
