Mean Well SFTN02N-05 DC/DC converter module 400mA 2W 1 output 1pc

Mean Well
Order Code:

05-1725

Brand: Mean Well MPN: SFTN02N-05 EAN-13: 4021087052016
Qty Unit Price (Ex VAT)
1+ £6.09
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well SFTN02N-05 is a DC/DC converter module with a current rating of 400 mA and a power output of 2 W. It features a single output and is ideal for applications requiring efficient voltage conversion in compact electronic circuits. This converter is commonly used in situations where precise direct current regulation is essential, such as in telecommunications and industrial control systems.
Connection Pins
Dim (L x W x H) 15.24 x 10.9 x 7.1 mm
Efficiency (max.) 78%
Height 7.1mm
Input voltage (max.) 26.4V DC
Insulation Voltage 3000V DC
Length 15.24mm
Max. output current 400mA
Min. input voltage 21.6V DC
Number of Outputs 1
Operating temperature (max.) +100°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 400mA
Output current (min.) 40mA
Output voltage (max.) 5V DC
Power 2W
PSU features DC-to-DC converter
Type DC/DC converter (module)
Width 10.9mm
