Mean Well SFTN02M-12 DC/DC converter 167 mA 2 W 1 output 1 pc

Mean Well
Standard range
Order Code:

05-1723

Brand: Mean Well MPN: SFTN02M-12
Qty Unit Price (Ex VAT)
1+ £5.40
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
12 in stock, despatched in 4 working days

The Mean Well SFTN02M-12 is a DC/DC converter module featuring a single output with a current rating of 167 mA and power output of 2 W. This module is well-suited for converting direct current in electronic circuits, ensuring efficient energy transformation. Typical applications include isolated power supplies and electronic devices requiring stable voltage outputs.
Type DC/DC converter (module)
Connection Pins
Dim (L x W x H) 15.24 x 10.9 x 7.1 mm
Efficiency (max.) 81%
Height 7.1mm
Input voltage (max.) 13.2V DC
Insulation voltage 3000V DC
Length 15.24mm
Max. output current 167mA
Min. input voltage 10.8V DC
Misc Attribute SFTN02M-12
No. of outputs 1
Operating temperature (max.) +100°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 167mA
Output current (min.) 33mA
Output voltage (max.) 12V DC
Power 2W
PSU features DC-to-DC converter
RoHS-compliant Yes
Weight 1.2g
Width 10.9mm
