Mean Well SFTN02L-12 DC/DC converter 2W 167mA 1 output 1pc

Mean Well
Order Code:

05-1720

Brand: Mean Well MPN: SFTN02L-12 EAN-13: 4021087052061
Qty Was Unit Price (Ex VAT)
1+ £6.47 £4.89
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well SFTN02L-12 is a DC/DC converter module designed with a single output and a current rating of 167 mA, delivering 2 W of power. This converter is suitable for direct current conversion in various electronic applications requiring compact and efficient power solutions. Typical uses include telecommunications equipment and portable electronic devices where reliable voltage regulation is needed.
Connection Pins
Dim (L x W x H) 15.24 x 10.9 x 7.1 mm
Efficiency (max.) 80%
Height 7.1mm
Input voltage (max.) 5.5V DC
Insulation Voltage 3000V DC
Length 15.24mm
Max. output current 167mA
Min. input voltage 4.5V DC
Number of Outputs 1
Operating temperature (max.) +100°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 167mA
Output current (min.) 33mA
Output voltage (max.) 12V DC
Power 2W
PSU features DC-to-DC converter
Type DC/DC converter (module)
Width 10.9mm
