Mean Well SDR-960-48 48V 20A DIN rail PSU overload PFC 1 output

The Mean Well SDR-960-48 is a rail mounted PSU designed for industrial applications, providing a stable 48 V DC output at 20 A. It features an enclosed design with a single output and is ideally suited for DIN rail mounting in control cabinets. This 960 W power supply unit is typically used in automation systems, machinery, and other industrial power applications.

Type	Rail mounted PSU (DIN)
Nominal value output current 1	20A
Number of Outputs	1
Power Rating	960W
Depth	110.00mm
Dimensions (L x W x H)	110.00 x 125.20 x 150.00mm
Height	150.00mm
Max. output current 1	20A
Maximum input voltage [AC]	264V
Minimum Input Voltage [AC]	180V
Misc Attribute 1	Synchronised
Nominal value output voltage 1 [DC]	48V
Number of Inputs	1
Type of electric connection	Screw terminal
Weight	2466.67g
Width	125.20mm
