Mean Well SCW20C-05 SCW20 dc/dc converter 4A 20W 1 output DIP24

Mean Well
Standard range
Order Code:

05-1641

Brand: Mean Well MPN: SCW20C-05
Qty Unit Price (Ex VAT)
1+ £24.86
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
3 in stock, despatched in 4 working days

The Mean Well SCW20C-05 is a DC/DC converter module with a single output supplying 4 A at 20 W. It is ideal for applications requiring reliable power conversion in electronic devices or systems. This converter ensures efficient voltage regulation and is suitable for use in industrial and communication equipment.
Type DC/DC converter (module)
Connection Pins
Dim (L x W x H) 31.8 x 20.3 x 12.2 mm
Efficiency (max.) 86%
Height 12.2mm
Input voltage (max.) 75V DC
Insulation voltage 1500V DC
Length 31.8mm
Max. output current 4A
Min. input voltage 36V DC
Misc Attribute SCW20C-05
No. of outputs 1
Operating temperature (max.) +80°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 4A
Output voltage (max.) 5V DC
Power 20W
PSU features DC-to-DC converter
Weight 18.5g
Width 20.3mm
