Mean Well SCW20A-15 SCW20 DC/DC converter 1.333A 20W 1 output 1pc

Mean Well
Standard range
Order Code:

05-1637

Brand: Mean Well MPN: SCW20A-15
Qty Unit Price (Ex VAT)
1+ £24.83
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
3 in stock, despatched in 4 working days

The Mean Well SCW20A-15 is a DC/DC converter module capable of delivering 1.333 A with a power output of 20 W and one output. This converter is well-suited for applications requiring stable voltage conversion in industrial and telecommunications equipment. Its compact design and reliable performance make it ideal for powering sensitive electronics from varying DC sources.
Type DC/DC converter (module)
Connection Pins
Dim (L x W x H) 31.8 x 20.3 x 12.2 mm
Efficiency (max.) 87%
Height 12.2mm
Input voltage (max.) 18V DC
Insulation voltage 1500V DC
Length 31.8mm
Max. output current 1.333A
Min. input voltage 9V DC
Misc Attribute SCW20A-15
No. of outputs 1
Operating temperature (max.) +80°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 1.33A
Output voltage (max.) 15V DC
Power 20W
PSU features DC-to-DC converter
Weight 18.5g
Width 20.3mm
