Mean Well SCW20A-05 SCW20 DC/DC converter module 4A 20W single output

Mean Well
Order Code:

05-1635

Brand: Mean Well MPN: SCW20A-05 EAN-13: 4021087048200
Qty Unit Price (Ex VAT)
1+ £25.51
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
2 in stock, despatched in 4 working days

The Mean Well SCW20A-05 is a DC/DC converter module with a power rating of 20 watts and a current capacity of 4 amperes. It features a single output suited for efficient power conversion applications. Typical applications include use in telecommunications, industrial control systems, and electronic devices requiring stable voltage conversion.
Connection Pins
Dim (L x W x H) 31.8 x 20.3 x 12.2 mm
Efficiency (max.) 86%
Height 12.2mm
Input voltage (max.) 18V DC
Insulation Voltage 1500V DC
Length 31.8mm
Max. output current 4A
Min. input voltage 9V DC
Number of Outputs 1
Operating temperature (max.) +80°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 4A
Output voltage (max.) 5V DC
Power 20W
PSU features DC-to-DC converter
Type DC/DC converter (module)
Width 20.3mm
