Mean Well RSDW08F-15 DC/DC converter 530 mA 8 W 1 output module

Mean Well
Standard range
Order Code:

05-1547

Brand: Mean Well MPN: RSDW08F-15
Qty Unit Price (Ex VAT)
1+ £16.48
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
2 in stock, despatched in 4 working days

The Mean Well RSDW08F-15 is a direct current converter module with a power rating of 8 watts and an output current of 530 mA. It offers one output, making it suitable for applications requiring a single stable DC output from various DC input sources. Typical applications include powering sensitive electronic systems and specialised equipment where dependable voltage conversion is crucial.
Type DC/DC converter (module)
Connection Pins
Dim (L x W x H) 31.8 x 20.3 x 10.2 mm
Efficiency (max.) 85%
Height 10.2mm
Input voltage (max.) 36V DC
Insulation voltage 1500V DC
Length 31.8mm
Max. output current 530mA
Min. input voltage 9V DC
Misc Attribute RSDW08F-15
No. of outputs 1
Operating temperature (max.) +90°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 530mA
Output voltage (max.) 15V DC
Power 8W
PSU features DC-to-DC converter
RoHS-compliant Yes
Weight 18.4g
Width 20.3mm
