Mean Well RPS-30-12 SMPSU 12V 2.5A 30W Single Output Power Supply

The Mean Well RPS-30-12 is a switch mode power supply unit (SMPSU) designed for mounting on printed circuit boards. It provides a 12 V DC output with a current rating of 2.5 A for a total power of 30 W, and includes solder lugs for secure connections. Typical applications include use in industrial equipment and electronic devices requiring efficient power conversion.

Type	SMPSU
Nominal value output current 1	0A
Number of Outputs	1
Power Rating	30W
Depth	76.2mm
Dimensions (L x W x H)	76.2 x 50.8 x 24mm
Height	24mm
Max. output current 1	2.5A
Maximum input voltage [AC]	264V
Maximum Temperature	+70°C
Min. temperature	-30°C
Minimum Input Voltage [AC]	80V
Misc Attribute 2	Pulsed
Misc Attribute 3	open
MTBF	628700h
Nominal value output voltage 1 [DC]	12V
Number of Inputs	1
PFC	No
PSU features	Adjustable voltage output
Type of electric connection	Pin strip for nylon crimp connectors
Weight	90g
Width	50.8mm
