Mean Well RPS-200-24 SMPSU 24V 8.4A 201.6W medical power supply

The Mean Well RPS-200-24 is a switch mode power supply unit with a 24 V DC output and an 8.4 A current rating, delivering up to 201.6 W. It is designed for PCB mounting with solder lugs, making it suitable for various electronic and industrial applications requiring stable power. Ideal for printed circuit board power supply applications, it provides reliable performance for machinery and electronic devices.

Type	SMPSU
Nominal value output current 1	8.4A
Number of Outputs	1
Power Rating	200W
Depth	101.6mm
Dimensions (L x W x H)	101.6 x 50.8 x 29mm
Height	29mm
Max. output current 1	8.4A
Maximum Temperature	+70°C
Min. temperature	-30°C
Misc Attribute 2	Pulsed
Misc Attribute 3	open
MTBF	500200h
Nominal value output voltage 1 [DC]	24V
Number of Inputs	1
PFC	No
Type of electric connection	Pin strip for nylon crimp connectors
Weight	190g
Width	50.8mm
