Mean Well RPS-200-24-C SMPSU 200W medical grade low leakage current

Mean Well
Order Code:

05-1456

Brand: Mean Well MPN: RPS-200-24-C EAN-13: 4021087034203
Qty Unit Price (Ex VAT)
1+ £78.80
5+ £76.42
10+ £74.07
25+ £71.71
50+ £69.53
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
4 available to back orderBack-order availability date - 11/01/2026

The Mean Well RPS-200-24-C is a printed circuit board power supply unit delivering 201.6 W at 24 V and 8.4 A. Designed for efficiency, this SMPSU includes solder lugs for secure mounting and is suitable for various electronic applications, including those requiring pin strip connections. Typical uses include powering industrial equipment and sensitive electronic devices where consistent, reliable performance is essential.
Output Voltage 24V DC
Output Current 8.4A
Number of Outputs 1
Connection Pin strip for nylon crimp connectors
Dimensions (L x W x H) 103.4 x 62 x 40 mm
Height 40mm
Length 103.4mm
Max. temperature +70°C
Min. temperature -30°C
Misc Attribute 2 Pulsed
Misc Attribute 3 closed
MTBF 500200h
PFC No
Type SMPSU
Width 62mm
