Mean Well RPS-200-12-C SMPSU 200.4W medical approved low leakage

Mean Well
Order Code:

05-1454

Brand: Mean Well MPN: RPS-200-12-C EAN-13: 4021087034241
Qty Unit Price (Ex VAT)
1+ £56.68
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 15/12/2025

Mean Well's RPS-200-12-C SMPSU is a printed circuit board power supply unit rated at 12 V and 16.7 A, delivering up to 200.4 W. It features a pin strip for nylon crimp connectors and is suitable for PCB mounting with solder lugs. This power supply unit is typically used in industrial and electronic applications requiring reliable and efficient power conversion.
Connection Pin strip for nylon crimp connectors
Dim (L x W x H) 103.4 x 62 x 40 mm
Height 40mm
Length 103.4mm
Max. output current 16.7A
Max. temperature +70°C
Min. temperature -30°C
Misc Attribute 2 Pulsed
Misc Attribute 3 closed
MTBF 500200h
Number of Outputs 1
Output current (max.) - rounded 16.7A
Output voltage (max.) 1V
Output voltage (min.) 12V DC
PFC No
Type SMPSU
Width 62mm
