Mean Well MSP-1000-15 SMPSU 17V DC 64A 960W switching power supply

Mean Well
Standard range
Order Code:

05-1206

Brand: Mean Well MPN: MSP-1000-15
Qty Unit Price (Ex VAT)
1+ £247.13
5+ £239.46
10+ £232.05
25+ £222.41
50+ £215.00
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
2 in stock, despatched in 4 working days

The Mean Well MSP-1000-15 is a switch-mode power supply unit (SMPSU) with an output of 17 V DC and a current capacity of 64 A, delivering a total power output of 960 W. Designed for PCB mounting with screw terminals, it features solder lugs for secure connections. This robust power supply is ideal for industrial applications requiring high power output and stable voltage regulation.
Type SMPSU
Connection Screw terminal
Dim (L x W x H) 218 x 105 x 63.5 mm
Height 63.5mm
Length 218mm
Max. output current 64A
Misc Attribute 1 MSP-1000-15
Misc Attribute 2 Pulsed
Misc Attribute 3 closed
MTBF 286300h
No. of outputs 1
Operating temperature (max.) +70°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 64A
Output voltage (max.) 17V DC
Output voltage (min.) 14V DC
PFC Yes
Power 960W
Weight 1530g
Width 105mm
