Mean Well MSP-1000-12 SMPSU 14V DC 80A 960W Single Output Power Supply

The Mean Well MSP-1000-12 is a single-output, 960 W switch-mode power supply unit designed for PCB mounting with screw terminals. It provides a 14 V DC output at a current of up to 80 A, making it ideal for high-power applications. This SMPSU is suitable for use in industrial automation, telecommunications, and other electronic equipment requiring a robust power solution.

Output Voltage	11V DC
Output Current	80A
Power Rating	960W
Number of Outputs	1
Input Voltage	180-264VAC
Connection	Screw terminal
Dimensions	(L x W x H) 218 x 105 x 63.5 mm
Height	63.5mm
Length	218mm
Maximum Operating Temperature	+70°C
Misc Attribute 2	Pulsed
Misc Attribute 3	closed
MTBF	286300h
Operating temperature (min.)	-40°C
PFC	Yes
Type	SMPSU
Weight	1530g
Width	105mm
