Mean Well MPM-10-12 AC/DC PSU 12V 850mA for medical devices compact design

Name: Mean Well MPM-10-12 AC/DC PSU 12V 850mA for medical devices compact design
Brand: Mean Well
Price: 6.98 GBP
Availability: InStock

Standard range

Order Code:

05-1164

Brand: Mean Well MPN: MPM-10-12

RoHS Compliant
Country of Origin: China
Free UK shipping available
View Full Product Range (3)

Inc VAT

Qty	Unit Price (Ex VAT)
1+	£6.98
5+	£6.77
10+	£6.57

Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT

1 in stock, despatched in 4 working days

Product Details
Product Range
Data Sheets
Quick Quote

Mean Well's MPM-10-12 is a printed circuit board power supply unit designed for AC/DC conversion. It features a voltage rating of 12 V DC and a current output of 850 mA, making it suitable for low-power applications. Typical uses include powering small electronic devices and components on printed circuit boards.

Type	AC/DC PSU (print)
Dim	(L x W x H) 45.7 x 25.4 x 21.5 mm
Efficiency to	83%
Height	21.5mm
Input frequency	47-440Hz
Input voltage (max.)	264V AC
Insulation voltage	4000V AC
Length	45.7mm
Max. output current	850mA
Min. input voltage	80V AC
Misc Attribute 1	MPM-10-12
Misc Attribute 2	Pulsed
Misc Attribute 3	1
No. of outputs	1
Operating temperature (max.)	85°C
Operating temperature (min.)	-30°C
Output current (max.) - rounded	850mA
Output current 1	850mA
Output voltage (max.)	12V DC
Output voltage 1	12V DC
Protection class	II
Residual ripple	180 mVp-p
Tolerance (output voltage)	±2,5%
Weight	35g
Width	25.4mm
