Mean Well MDD01M-15 DC/DC converter module 34mA 1W 2 outputs 1pc

Mean Well
Standard range
Order Code:

05-1097

Brand: Mean Well MPN: MDD01M-15
Qty Unit Price (Ex VAT)
1+ £5.16
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
2 in stock, despatched in 4 working days

The Mean Well MDD01M-15 is a DC/DC converter module with a power rating of 1 W and a current rating of 34 mA. It features two outputs and is suitable for applications requiring reliable voltage conversion. Typical uses include electronic devices needing stable power supply across varied voltage levels.
Type DC/DC converter (module)
Connection Pins
Dim (L x W x H) 19.5 x 9.8 x 12.5 mm
Efficiency (max.) 76%
Height 12.5mm
Input voltage (max.) 13.2V DC
Length 19.5mm
Max. output current 34mA
Min. input voltage 10.8V DC
Misc Attribute MDD01M-15
No. of outputs 2
Operating temperature (max.) +85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 34mA
Output current (min.) 4mA
Power 1W
PSU features DC-to-DC converter
Weight 4.2g
Width 9.8mm
